IS440.1 5G Radio for Zone 1/21
Ask for price
The 5G radio ensures secure and failure-free PoC communication via public or campus networks (4G or 5G) or Wi-Fi in Ex-Zone 1/21. A gateway makes the IS440.1 interoperable with previous radio technologies and enables a seamless integration into existing systems. The 5G radio offers a user-orientated look & feel, a replaceable battery, large buttons for PTT, SOS, talkgroup selection, a powerful front speaker, an ISM interface and a functional fixing clip. You can download selected apps that are compatible with the device directly from the pre-installed App World and update them regularly. The App World contains product-related, selected push-to-talk and MDM solutions.
Advantages
- Channel selector e.g. for PTT applications
- Programmable red key (e.g. for lone worker protection/SOS)
- Programmable side key (e.g. for PoC/PTT)
- Additional programmable buttons, M1 & M2, assignable via Button App
- 8-pin ISM interface for optional audio accessories
- Powerful 4800 mAh battery for extreme runtime as an optional accessory
- Amplified loudspeaker for noisy work environments
- Integrated belt clip for safe carrying
Description
Product Details
Technical features
Operating system
- ISM-OS
Processor
- Qualcomm QCM6490 Octa Core
Memory
- 4 GB RAM
- 64 GB internal memory
Frequencies
- 4G LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12 MFBI/B13/B14/B17/B20/B25/B26/B28/B29/B30/B66/B71/B68
- 4G LTE-TDD: B38/B39/B40/B41/B42/B43/B48
- 5G NR: n1/n2/n3/n5/n7/n8/n12/n14/n20/n25/n28/n30/n38/n40/n41/n48/n66/n71/n77/n78/n79
Dimensions
- Size: 136,6 x 70 x 32 mm
- Weight: 307 g
Display
- 2,4” (6,096 cm) Corning Gorilla Glass V3
Battery
- 2400 mAh
- Replaceable
Camera
- 8 MP AF front
Connectivity
- Wi-Fi 6: IEEE 802.11 a/b/g/n/ac/e/k/r/ax/v with hotspot
- Bluetooth 5.2
- GPS, A-GPS, Glonass, Beidou, Galileo, NavIC, QZSS, SBAS
- Near Field Communication
Types of protection
- IP68 dust-/waterproof
- MIL-STD 810H
- Usable from -20 °C to +55 °C
Further features
- Amplified loudspeaker
- Accelerometer, Gyroscope, Magnetic, Pressure sensors
- Dual-SIM (Nano-SIM + eSIM)
- USB-C, Desktop Charger, Multi Charger
- Function key red (function key assignable for different 3rd party application; e.g. loneworker protection)
Approvals
ATEX (Europe) approved
- II 2G Ex ib IIC T4 Gb
- II 2D Ex ib IIIC T135°C Db
IECEx (International) approved
- Ex ib IIC T4 Gb
- Ex ib IIIC T135°C Db
NEC500 (North America) approved
- Class I Div. 1 Groups A, B, C, D, T4
- Class II Div. 1 Groups E, F, G, T135 °C
- Class III
IA (South Africa) approved
- Ex ib IIC T4 Gb
- Ex ib IIIC T135°C Db
INMETRO (Brazil) approved
- Ex ib IIC T4 Gb
- Ex ib IIIC T135°C Db
PCEC (China) approved
- Ex ib IIC T4 Gb
- Ex ib IIIC T135°C Db
KCs (South Korea) applied for
- Ex ib IIC T4 Gb
- Ex ib IIIC T135°C Db
Contents included
- 5G Radio
- Battery
- i.safe PROTECTOR 2.0
- Power Adapter universal
- Safety Instructions
- Screwdriver
- Display Protection Foil
Full technical specification is available in Attachments.
Data sheet
| Connectivity | 4G 5G |
|---|---|
| Display | 2,4" |
| Camera | 8 MP AF front |
| Battery | 2400 mAh |
| RAM | 4 GB |
| Internal memory | 64 GB |
| Operating system | ISM-OS |
