TRB141 Gateway
Ask for price
Industrial Rugged GPIO LTE Gateway
Connectivity: 4G/LTE (Cat 1), 3G, 2G
Durability: rugged aluminium housing
I/O: wide range of multiple Inputs/Outputs for remote monitoring and control
9-30V: wide range of supported power supply voltages
Compactness: small size, easy installation
RMS: compatible with Teltonika Remote Management System
Description
Product Details
This small industrial LTE Cat 1 gateway is equipped with a micro USB and various Input/Output options, including Digital, Relay, Analog, and Isolated. Paired with secure and functional RutOS, plenty of processing power, and Teltonika Networks Remote Management System (RMS), this device offers unprecedented application flexibility to manage and control equipment remotely over LTE Cat 1. It has a wide range of software features such as SMS control, VPN, IPsec, Firewall, and FOTA support. Perfect for application scenarios, where devices must be remotely managed using Inputs/Outputs. The device offers a wide range of supported power supply voltages (9-30 V) and operating temperatures (-40°C ~ +75°C).
Standard package contains
- TRB141 Gateway
- 9W PSU
- 1 x LTE antenna (magnetic mount, SMA male, 3 m cable)
- Micro-USB cable (0.8 m)
- 1 x hex key
- I/O connector
- QSG (Quick Start Guide)
- RMS Flyer
- Packaging box
Full technical specification is available in Attachments.
Data sheet
| Operating voltage | 9-30 VDC |
|---|---|
| Connectivity | 2G 3G 4G/LTE Cat 1 |
| Maximum power consumption | 5 W |
| Dimensions | 74,5 x 25 x 64,4 mm |
| Weight | 136 g |
| Mounting options | DIN rail flat surface wall |
| Operating temperature | -40°C - 75°C |
| IP degree of protection | IP30 |
| USB ports | 1 |
| Digital inputs | 3 |
| Configurable I/O | 2 |
| SIM slots | 1 |
| Analog inputs | 1 |
| Relays | 2 |
| Operating system | RutOS (OpenWrt based Linux OS) |
| VPN | IPsec OpenVPN WireGuard |
