RUTX10 Router
Ask for price
Professional Ethernet Router
Gigabit Ethernet: 4 x Gigabit Ethernet ports with up to 128 port/tag-based VLANs supported
I/O and USB: digital Input / Output for remote monitoring and control and USB 2.0 interface
WIFI and BT: Wave-2 802.11ac Dual Band WIFI and Bluetooth LE
Protocols: multiple protocols supported including MQTT, Modbus TCP, BGP, GRE
Security: firewall and numerous vpn services including OpenVPN, Ipsec, PPTP, L2TP i DMVPN
RMS: compatible with Teltonika Remote Management System
Description
Product Details
We created RUTX10 Enterprise router specially for small to mid-size office applications. It comes with Dual Band Wi-Fi 5 802.11ac, which is very suitable for high data transmission and robust wireless performance. It has all the latest security features and allows remote monitoring and control. RUTX10 comes with highly functional & customizable RutOS based on OpenWRT. Synergy between hardware and software makes this device an amazing performer in Enterprise solutions. The device offers a wide range of supported power supply voltages (9-50 V) and operating temperatures (-40°C ~ +75°C).
Standard package contains
- RUTX10 Router
- 18 W PSU
- 2 x WiFi antennas (swivel, RP-SMA male)
- 1 x Bluetooth antenna (magnetic mount, RP-SMA male, 1.5 m cable)
- Ethernet cable (1.5 m)
- QSG (Quick Start Guide)
- RMS Flyer
- Packaging box
Full technical specification is available in Attachments.
Data sheet
| Ethernet ports | 4 |
|---|---|
| Ethernet speed | 10/100/1000 Mbps |
| Operating voltage | 9-50 VDC |
| WiFi standard | IEEE 802.11b/g/n/ac Wave 2 |
| Maximum power consumption | 9 W |
| Dimensions | 115 x 32,2 x 95,2 mm |
| Weight | 355 g |
| Mounting options | DIN rail flat surface wall |
| Operating temperature | -40°C ~ +75°C |
| IP degree of protection | IP30 |
| USB ports | 1 |
| Digital inputs | 1 |
| Digital outputs | 1 |
| Operating system | RutOS (OpenWrt based Linux OS) |
| VPN | IPsec OpenVPN WireGuard |
