RUTX09 Router
Ask for price
Industrial Cellular Router
4G LTE Cat 6: cellular speeds up to 300Mbps with Carrier Aggregation
Dual SIM: with auto failover, backup WAN and other switching scenarios
Gigabit ETH: 4 x Gigabit Ethernet ports with up to 128 port/tag-based VLANs supported
GNSS: Global Navigation Satellite System for location services and time synchronization
Security: firewall and numerous VPN services including OpenVPN, IPsec, PPTP, L2TP and DMVPN
RMS: compatible with Teltonika Remote Management System
Description
Product Details
RUTX09 is LTE-A Cat 6 cellular IoT router with Dual-SIM, Carrier Aggregation, and 4 Gigabit Ethernet interfaces. RUTX09 is designed as a Main/Backup internet source offering cellular speeds up to 300 Mbps, where steady connection and high data throughput is necessary. It has plenty of processing capacity for custom applications on the OpenWrt based RutOS system. Plenty of security features are available, like Firewall, VPN, IPsec, SNMP, Content Filtering for maximized safety. This product is compatible with our Remote Management System for convenient monitoring, maintenance, and data collection. The device offers a wide range of supported power supply voltages (9-50 V) and operating temperatures (-40°C ~ +75°C).
Standard package contains
- RUTX09 Router
- 18W PSU
- 2 x LTE antennas (swivel, SMA male)
- 1 x GNSS antenna (adhesive, SMA male, 3 m cable)
- SIM Adapter kit
- Ethernet cable (1.5 m)
- QSG (Quick Start Guide)
- RMS Flyer
- Packaging box
Full technical specification is available in Attachments.
Data sheet
| Ethernet ports | 4 |
|---|---|
| Ethernet speed | 10/100/1000 Mbps |
| Operating voltage | 9-50 VDC |
| Connectivity | 3G 4G/LTE Cat 6 |
| Maximum power consumption | 9 W |
| Dimensions | 115 x 44,2 x 95,1 mm |
| Weight | 455 g |
| Mounting options | DIN rail flat surface wall |
| Operating temperature | -40°C - 75°C |
| IP degree of protection | IP30 |
| USB ports | 1 |
| Digital inputs | 1 |
| Digital outputs | 1 |
| GNSS | BeiDou GLONASS GPS Galileo QZSS |
| SIM slots | 2 |
| Operating system | RutOS (OpenWrt based Linux OS) |
| VPN | IPsec OpenVPN WireGuard |
