RUTX11 Router
Ask for price
Industrial Cellular Router
4G LTE Cat 6: cellular speeds up to 300Mbps with Carrier Aggregation
Dual SIM: with auto failover, backup WAN and other switching scenarios
WIFI & BT: Wave-2 802.11ac Dual Band WIFI and Bluetooth LE
GNSS: Global Navigation Satellite System for location services and time synchronization
Protocols: multiple protocols supported including MQTT, Modbus TCP, BGP, GRE
RMS: compatible with Teltonika Remote Management System
Description
Product Details
RUTX11 is a very powerful device equipped with Dual-SIM with auto Failover, Backup WAN, and other SW features. A wide range of internal hardware interfaces allows this product to be used in power-hungry industrial applications where speed and robustness are at the heart of the solution. 4G LTE – Cat 6 DL up to 300 Mbps in sync with 4 x 1 Gbit Ethernet ports allows for a seamless data transfer experience with auto-failover and a backup WAN. Bluetooth LE allows sensors to be connected directly to the router, thus minimizing the overall solution ecosystem. The device offers a wide range of supported power supply voltages (9-50 V) and operating temperatures (-40°C ~ +75°C).
Standard package contains
- RUTX11 Router
- 18W PSU
- 2 x LTE antennas (swivel, SMA male)
- 2 x WiFi antennas (swivel, RP-SMA male)
- 1 x GNSS antenna (adhesive, SMA male, 3 m cable)
- 1 x Bluetooth antenna (magnetic mount, RP-SMA male, 1.5 m cable)
- Ethernet cable (1.5 m)
- SIM Adapter kit
- QSG (Quick Start Guide)
- RMS Flyer
- Packaging box
Full technical specification is available in Attachments.
Data sheet
| Ethernet ports | 4 |
|---|---|
| Ethernet speed | 10/100/1000 Mbps |
| Operating voltage | 9-50 VDC |
| Connectivity | 3G 4G/LTE Cat 6 |
| WiFi standard | IEEE 802.11b/g/n/ac Wave 2 |
| Maximum power consumption | 16 W |
| Dimensions | 115 x 44,2 x 95,1 mm |
| Weight | 456 g |
| Mounting options | DIN rail flat surface wall |
| Operating temperature | -40°C - 75°C |
| IP degree of protection | IP30 |
| USB ports | 1 |
| Digital inputs | 1 |
| Digital outputs | 1 |
| GNSS | BeiDou GLONASS GPS Galileo QZSS |
| SIM slots | 2 |
| Operating system | RutOS (OpenWrt based Linux OS) |
| VPN | IPsec OpenVPN WireGuard |
