TSW110 Switch
Ask for price
L2 Unmanaged Switch
Plug-N-Play: no additional configuration needed
Durability: Rugged aluminium housing
Mounting: DIN rail and surface mounting options
Status LEDs: 1 x Power, 10 x Ethernet
9-30 V: Wide range of supported power supply voltages
Gigabit Ethernet: 5 x Gigabit Ethernet with speeds up to 1000 Mbps
Description
Product Details
TSW110 is a layer 2 unmanaged switch, which is a simplified version of our earlier product – TSW100. Possible to power up through the first LAN port. It has five 10/100/1000 Mbps Ethernet ports for an economical high-bandwidth solution. It offers a wide range of supported power supply voltages (9-30 V) and operating temperatures (-40°C ~ +75°C). Ideal for professional high bandwidth applications to provide reliable data connection.
Standard package contains
- TSW110 Switch
- 9W PSU
- QSG (Quick Start Guide)
- Packaging box
Full technical specification is available in Attachments.
Data sheet
| Ethernet ports | 5 |
|---|---|
| Ethernet speed | 10/100/1000 Mbps |
| Operating voltage | 9-30 VDC |
| Maximum power consumption | 1,8 W |
| Dimensions | 100 x 30 x 85 mm |
| Weight | 227 g |
| Mounting options | DIN rail flat surface wall |
| Operating temperature | -40°C - 75°C |
